Product Specifications

Certifications UL/FCC/RoHS (power supply)
Data + PoE Ports 1
Data Ports 1
Data Rate 10/100
Dimensions 1x5x5 in.
Input voltage 24 volts
LEDs Per Port 1
Max. Amps Per Port 2
Operating Humidity 5% to 90%
Operating Temperature Range -10 -60C
Output Voltage 5 volts
PoE Method Passive
PoE Mode/Pinout Mode B (+4,5 -7,8)
PoE Standard N/A
Power Input 2.1mm DC
Weight 6oz
  • Will this work to provide PoE to my Revolabs Flx2 base? Spec is for 5v and 1A. Happy to buy it if it will be compatible.

    Yes, this kit will include everything you need (except for cat 5 cable) to supply POE to the Base Station of your Revolabs Flx2.

  • does the connector stop charge when the battery is full ? (over charge)

    The WS-POE-5V10W will always provide power when plugged into a PD. Unless your device is a Quick Charge certified device, yes the device will stop taking power when the battery is full. Most devices are not certified and do not support this feature.
