How to Build a PoE-Powered Smart Mirror: The Ultimate Setup Guide (Part 1)

Have you ever wanted to upgrade your morning routine with a touch of the future? Smart mirrors mirrors that display the time, weather, and calendar while you brush your teeth are the ultimate DIY tech project.

But there is one major hurdle every DIYer faces: Power. Traditionally, you’d have to hide bulky power strips or drill massive holes in your wall to plug in a monitor and a Raspberry Pi.

In this guide, we’re looking at a smarter way to build: Power over Ethernet (PoE). By using a single Ethernet cable to deliver both data and electricity, you can create a sleek, professional installation. Let’s dive into the essential components and the layout for Part 1 of the Smart Mirror project.

Why Use PoE for a Smart Mirror?

The biggest challenge with wall-mounted tech is aesthetics.

• One Cable to Rule Them All: PoE allows you to run a single Cat5e or Cat6 cable to the mirror.

• Flexibility: You don’t need an electrician to install a new AC outlet behind the mirror.

• Reliability: Unlike Wi-Fi, which can be spotty behind glass and metal, a hardwired Ethernet connection ensures your mirror stays updated 24/7.

The Essential Parts List

To get this project off the ground, you’ll need a mix of hardware and specialized PoE components. Here is the breakdown from the PoE Texas build:

1. The Brains: Raspberry Pi 3B+

The Raspberry Pi is the industry standard for smart mirrors. It’s small, powerful enough to run the "MagicMirror²" software, and most importantly it is compatible with PoE hats.

2. The Power: PoE Texas Splitter/Injector

To get power from your Ethernet cable into the Pi and the Monitor, you need:

• PoE Switch or Injector: This adds power to your network cable.

• 5V PoE Splitter: This takes the PoE signal and splits it into a Micro-USB or USB-C connection to power the Raspberry Pi.

3. The Display: LCD Monitor

You’ll want a monitor with the bezel removed (de-bezeled) to keep the mirror as thin as possible. Ensure your monitor is compatible with the power output of your PoE splitter if you plan to power the screen via PoE as well.

4. The Magic: Two-Way Glass

This isn't a standard mirror. You need a "two-way" acrylic or glass sheet. It allows the light from the monitor to shine through from behind while remaining reflective on the front.

The Project Layout: How It Works

The goal of Part 1 is to "breadboard" the project setting everything up on a table before mounting it in a frame.

1. The Network Source: An Ethernet cable runs from your PoE switch.

2. The Splitter: The cable plugs into the PoE Texas splitter.

3. Data & Power: The splitter provides a 5V power output for the Raspberry Pi and passes the data connection through.

4. The Interface: The Pi connects to the monitor via HDMI.

5. The Software: Most builders use the MagicMirror² open-source platform, which allows you to drag and drop "modules" like Google Calendar, Spotify, and Weather reports.

Pro-Tip: Managing Heat

When you eventually put these components inside a wooden frame behind a piece of glass, heat can become an issue. The PoE Texas setup is ideal because PoE splitters often run cooler than traditional AC-to-DC "wall wart" adapters, and the Raspberry Pi 3B+ has excellent community support for low-profile cooling fans.

What’s Next?

Building the "skeleton" of your smart mirror is only the beginning. Once you have your Raspberry Pi powered via PoE and your monitor displaying the interface, it’s time for the "nitty-gritty."

In Part 2, the focus shifts to:

• Coding: Configuring the Raspbian OS and MagicMirror software.

• The Build: Framing the glass and mounting the electronics.

• The Reveal: Seeing the finished product flush against the wall with zero visible wires.
