4 Port Active Gigabit Mode A PoE Injector with 48 Volt 30 Watt Power Supply

SKU AT-4-48V30W
Sold out
$67.99

Active PoE means the right power at the right time. An active PoE injector negotiates with the powered device to deliver the voltage needed, so there are no concerns about accidentally burning out lower powered or non-PoE devices. Power is only added to the data cable when an 802.3af or 802.3at device is connected.

Product Features:

  • Instantly upgrade your network switch to PoE+ for 802.3at devices like VOIP phones, WiFi Access Points, Cameras and More
  • Active negotiation protects non-PoE devices
  • Mode A power delivery (pins 1,2- / 3,6+)
  • Includes a 48 volt, 30 watt power supply
  • Shielded RJ45 ports
  • 650mA self-resetting fuse / 30 watts per port
  • Supports 4 x 802.3af devices (up to 15 watts each) or 2 x 802.3at devices (up to 30 watts each)
See the Online Technical Manual

Product Specifications

Certifications CE, FCC, RoHS, UL (power supply)
Data + PoE Ports 4
Data Ports 4
Data Rate Gigabit
Dimensions 4.5 x 2 x 1 in.
Max Amps Per Kit 1.25 Amps
Max Power for Kit 60 Watts
Max. Amps Per Port 650 mA
Mount Type Wall
Operating Humidity 5% to 90%
Operating Temperature Range -10 - 60C
Output Voltage 48 volts
PoE Method Active
PoE Mode/Pinout Mode A (-1,2 +3,6)
PoE Standard 802.3af; 802.3at
Power Input 2.1mm DC
Power Supplies PS-48v60w
