Product Specifications

Certifications UL/CE/FCC
Data + PoE Ports 6
Data Ports 6
Data Rate Gigabit
Dimensions 6 x 3 x 1 in.
Input voltage 24 Volts
Max Amps Per Kit 2.5 Amps
Max Power for Kit 60 Watts
Max. Amps Per Port 650 mA / 1.25 (With Y-cable)
Mount Type Wall
Operating Humidity 5% to 90%
Operating Temperature Range -10 - 60C
Output Voltage 24 volts
PoE Method Passive
PoE Mode/Pinout Mode A (-1,2 +3,6)/Mode B (+4,5 -7,8)
Power Input 2.1 x 5.5 mm DC
Power Supplies PS-24v60w
